WATER PUMP
ENGINE COOLING
14-21
INSTALLATION SERVICE POINT
>>A<< O-RING INSTALLATION
CAUTION
Do not let the O-ring get contaminated with
grease or engine oil.
AC103005
Water pump
O-ring
Water inlet pipe
AC
Fit an O-ring into the O-ring groove located at the
end of the water inlet pipe and apply water to the
O-ring or the inside of the mounting surface of the
water pump for insertion.
