Mitsubishi Lancer Evolution IX 2006 User Manual

TROUBLESHOOTING
ENGINE COOLING
14-4
INSPECTION PROCEDURE FOR
TROUBLE SYMPTOMS
INSPECTION PROCEDURE 1: Cooling fan does not operate
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet PU : Purple
INPUT SIGNAL
· A/C SWITCH
· ENGINE
COOLANT
TEMPERATURE
SENSOR
· VEHICLE SPEED
SENSOR
ENGINE-
ECU
ENGINE
CONTROL
RELAY
SMOOTHING
CIRCUIT
FIELD EFFECT
TRANSISTOR
CIRCUIT
INPUT SIGNAL
PROCESSING
DRIVE
CIRCUIT
TEMPERATURE
DETECTION
CURRENT
DETECTION
RADIATOR
FAN
MOTOR
FAN CONTROLLER
ENGINE
CONTROL
SYSTEM
FUSIBLE
LINK
2
FAN
CONTROL
RELAY
AC505138
Cooling fan drive circuit <L.H. drive vehicles>
AB
