EXTERIOR – FRONT BUMPER, REAR SPOILER
51-4
Disassembly Procedure
1. Three diamond mark
2. Licence plate trim
3. Licence plate bracket
4. Licence plate bracket assembly
5. Cover
6. Front air dam panel
7. Front bumper lower plate assembly
8. Front bumper lower reinforcement
assembly
9. Front bumper reinforcement assembly
10. Bumper net
11. Front bumper side cover
12. Bumper side net (LH)
13. Oil cooler duct
14. Bumper side net (RH)
• Water spray hose and nozzle
(see Chap. 15)
15. Front bumper side plate assembly
16. Front bumper upper reinforcement
assembly
17. Front bumper face
Disassembly service points
A
Removal of front bumper side plate
Use the same procedure as that for removal of front bumper rivets
in previous model.
Reassembly service points
A
Installation of front bumper side plate
Use the same procedure as that for installation of front bumper
rivets in previous model.
Rear Spoiler
Adhesive
A
A
Application Brand
Rear Spoiler Double-sided tape : Generic product A (width 5 mm, thickness 0.8 mm); B (width 5 mm,
thickness 1.2 mm)
Double-sided tape removing agent : Sumitomo 3M 4000 double-sided tape remover (made
by Sumitomo 3M)
Primer : Sumitomo 3M 8107 parts primer (made by Sumitomo 3M)
To Next Page
