10
3. Vehicle Immobilization and Stabilization
WARNING:
- When installing a "block" or "lift airbag device", avoid high-voltage parts, exhaust systems and fuel systems, etc.
- If high-voltage components or high-voltage harnesses are exposed, do not place any support on them.
It may cause damage or fire for vehicle.
NOTE:
When the 12V starter battery is weak or dead or disconnect to terminal the Electric parking brake cannot be applied
or released.
・Immobilization with wheel chocks
Park the vehicle and press the Electric parking switch.
Pull up the Electric parking brake switch while depressing the brake pedal, Check for the indicator lamp (Red) on the
combination meter will come on.
Once the wheels are locked, lock the vehicle with the wheel chocks.
CAUTION:
- When applying the electric parking brake, stepping on the brake pedal firmly, stop completely the vehicle, and then pull
up the switch.
・Stabilize with block
To stabilize the vehicle, place a support such as a block for under the vehicle and release air from tires to
stabilize the vehicle.
When fixing the vehicle to the foundation, use the designated position of the jack.
*: Refer to “10. Explanation of pictogram used”
Brake warning light
For U.S.A
For CANADA/MEXICO
Electric parking brake switch
To Next Page
