3.Disable direct hazards / safety regulations
NOTE:
Disconnecting the 12V starter battery may make it impossible to perform operations related to electrical
components. Perform the necessary operations before removing the 12V starter battery terminal.
The OUTLANDER PHEV is equipped with a lithium-ion battery of max. voltage 336V.
This is used to activate the electric motor unit and some components such as air conditioning.
Before rescue work can begin, it is necessary to ensure “isolation” and “cut off” from the high voltage circuit in
order to prevent the risk of electric shock before handling the vehicle.
Drive battery specification is “13.8kWh lithium-ion, 300V”. Drive battery’s maximum voltage capacity is 336V when
the Drive battery is being charged.
CAUTION:
Silence does not always mean that the hybrid system is turned off.
Ensure that the high voltage circuit is “isolated” or “cut off”.
(1) Isolation from the high voltage circuit
1) The high voltage circuit is insulated from the vehicle body.
2) All of high voltage components are covered up by cases and covers.
Note that high voltage wiring cables can be distinguished from normal wiring harness by their orange coloured
insulation.
3) The cases and covers are insulated from the high voltage circuit inside.
(2) Disconnection of the high voltage circuit
1) This vehicle has a system which allows the high voltage current supplied from the drive battery to be
isolated automatically if you cannot isolate the high voltage system due to service maintenance or an accident.
2) The high voltage circuit will be isolated by pulling the charging connector during the battery charging.
<Disconnection mode>
System
Case
Manual mode
Automatic mode
Charging connector
Service plug
Electric motor switch
linked
Collision sensing
Normal usage
N/A
N/A
Available
N/A
During inspection or
maintenance
N/A
Available
Available
N/A
Collision accident
N/A
N/A
N/A
Available
During the battery
charging
Available
N/A
N/A
N/A
(3) Precautions when rescuing passengers
WARNING:
Failure to follow these instructions may result in serious injury such as electric shock:
(1) This vehicle is equipped with a high voltage system of max operation voltage 336V.
(2) The possibility of a high volume electrolyte leak as a result of the drive battery damage is reduced by the design
inside the drive battery.
(3) Drive battery uses an electrolyte made of flammable “Carbonate ester solution of lithium salts”.
When reacting with moisture in the air, this electrolyte generates acidic organic vapour which is harmful to human body.
Therefore, when handling this, please use appropriate Personal Protective Equipment (PPE) including mask for
organic gas, solvent resistance gloves and eye protector and use appropriate caution.
(4) Vehicles with Mitsubishi remote control have an 12V starter battery charging and a remote climate control
functions. Therefore, even if the indicator in the electric motor switch is off, the high voltage system may be
active.
