5 DATA USED FOR POSITIONING CONTROL
Storage buffer
memory address
Reading the monitor value
Default
value
Axis 1 Axis 2 Axis 3 Axis 4
Monitoring is carried out with a decimal display.
00: Block start (Normal start)
01: Condition start
02: Wait start
03: Simultaneous start
04: FOR loop
05: FOR condition
06: NEXT
Storage value
Monitor
v
alue
0 827 927 1027 1127
Monitoring is carried out with a decimal display.
Storage value
Monitor value
setting value
Md.36
00
06
01
02
03
05
04
1 to 10
0 to 255
Stored contents Storage value
None
None
Condition data
No. of
repetitions
0 828 928 1028 1128
Monitoring is carried out with a decimal display.
Storage value
1 to 600
Monitor
value
0 829 929 1029 1129
Monitoring is carried out with a decimal display.
Storage value
Monitor
value
0: Not in speed limit (OFF)
1: In speed limit (ON)
0 830 930 1030 1130
Monitoring is carried out with a decimal display.
Storage value
Monitor
value
0: Not in speed change (OFF)
1: In speed change (ON)
0 831 931 1031 1131
