Mitsubishi QD75M2

11 - 34
MELSEC-Q
11 MANUAL CONTROL
Start time chart
Pulse input A phase
OFF
ON
OFF
OFF
1
t
OFF
00
1
Forward run
Reverse run
ON
Pulse input B phase
BUSY signal
QD75 READY signal
PLC READY signal
Start complete signal
Error detection signal
[Y0]
[X0]
[X10]
[XC]
[X8]
Cd. 21 Manual pulse generator
enable flag
Cd. 20 Manual pulse generator
1 pulse input magnification
OFF
ON
A
ll axis servo ON
[Y1]
OFF
ON
Fig. 11.20 Manual pulse generator operation start time chart
