Appendix - 53
MELSEC-Q
APPENDICES
Comparisons of performance specifications (Continued)
Model
Item
QD75M1 QD75M2 QD75M4 A1SD75M1 A1SD75M2 A1SD75M3
CHG signal
External command signal (External start or
speed-position switching selectable with
parameters)
Speed-position switching signal
In-position (INP)
(for monitor)
(for monitor)
I/O signal for
external devices
Signal logic switching
Command pulse output signal only
Connection with peripheral
devices
Connection via PLC CPU,
Q Corresponding Serial Communication
Module, Q Corresponding MELSEC/H
Remote I/O Module
Direct connection
AD71TU
AD75TU
A6GPP, A6PHP
A7GPP, A7PHP
PC9800
R
series
Peripheral devices
(data setting, etc.)
DOS/V personal computer
: Possible, : Not possible
1: Up to 100 data items/axis of positioning data (No. 1 to 100) can be set using the buffer memory. The positioning data in the buffer
memory is not backed up.
2: Indicates the INC mode/ABS mode in speed-position switching control.
3: The near pass function is valid only during the continuous path control. (A1SD75: Selected with parameters, QD75: Standard function)
(2) Function comparisons
Functions added to those of A1SD75M1/A1SD75M2/A1SD75M3
Added functions Remarks
External I/O signal logic switching function Refer to section 13.4.
Inching operation Refer to section 11.3.
Target position change function Refer to section 12.7.5.
Multiple axes simultaneous start control Refer to section 10.5.
Control systems
3-axis linear interpolation control
4-axis linear interpolation control
3-axis fixed-feed control
4-axis fixed-feed control
2-axis speed control
3-axis speed control
4-axis speed control
Position-speed switching control
NOP instruction
LOOP instruction, LEND instruction
Refer to chapter 9.
Dedicated
instructions
Positioning start
Teaching
Flash ROM writing
Parameter initialization
Refer to chapter 14.
Automatic refresh of intelligent function modules Refer to GX Configurator-QP Operating Manual.
Output hold/clear parameter setting during PLC CPU error stop
Refer to QCPU (Q mode) User's Manual (Function Explanation,
Program Fundamentals).
Flash ROM write limit Refer to section 13.3.
Speed-position switching control (ABS mode) Refer to section 9.2.17.
Pre-reading start function Refer to section 12.7.8.
External I/O signal monitor function Refer to section 13.5.
Multiple CPU correspond function
Refer to QCPU (Q mode) User's Manual (Function Explanation,
Program Fundamentals).
Absolute positioning system (degree unlimited length feed can be
configured)
Refer to section 12.6
