9 SPRING CLAMP TERMINAL BLOCK
(8) List of introductory products
The tools and the bar solderless terminal used for wiring the spring clamp
terminal block I/O module are listed below.
Manufacturer Name of product Model name Applicable wire size
Mitsubishi Electric System & Service Co.,
Ltd.
Spring clamp terminal
block tool
KD-5339
―
Nichifu Co.,Ltd.
Bar solderless terminal
*1
TE 0.5-8
TE 0.5-10
0.3 to 0.5 mm
2
(22 AWG)
TE 0.75-8
TE 0.75-10
0.75 mm
2
(20 AWG)
TE 1.0-8
TE 1.0-10
1.0 mm
2
(18 AWG)
TE 1.5-8
TE 1.5-10
1.5 mm
2
(16 AWG)
Bar solderless terminal tool NH79
―
*1: Use this product when doing the terminal treatment of the wire and inserting it into the
spring clamp terminal block.
