Mitsubishi SCM100ZJ-S1 User Manual

-
230
-
'11 • SCM-SM-110
Control PCB (PWB1) o n the 1st layer
Layout of control P CB.
Sub PCB (PWB4) on the 1st layer
1. Disconnect all connectors
from Sub PCB.
Note: Be sure to do this work
after elapsing 3 minutes
from power OFF.
〈Control PCB〉
〔Part side〕
〔Pattern side〕
CNEEV1
CNFAN1CNI1
CNA1
CNWCNL1 CNS1CNP1
CNI3
CNX1CNTH
CNN1CNA2 CNR1
CNA
(RD)
CNB
(BR)
CND
(YE)
CNE
(OR)
CNF
(PK)
CNC
(BL)
PK
OR
YE
BL
BR
RD
CNS2
CNX2
CNDRM
CNEEV1
CNTRICNTRO
CNEEV2
CNEEV3
CNEEV4
〔Before disconnecting connectors〕 〔After disconnecting connectors〕
