240
-
'11 • SCM-SM-110
EEVB
EEVC
EEVA
EEVD
EEVF
(125 only)
EEVE
MARKING
YELLOW
BLACK
GREEN
BLUE
RED
WHITE
＜Fan motor＞
＜EEVA - EEVF＞
＜EEV-H＞
46Ω
WH
46Ω
46Ω 46Ω
M
YE
OR
BL
RD
Input : 12VDC
46Ω
WH
46Ω
46Ω 46Ω
M
YE
OR
BL
RD
Input : 12VDC
CNFAN1 on PCB1
③
④
RD
BL
BR
OR
WH
①
②
NO. Output
① 280VDC
② 15VDC
③ 0-6VDC
④ 0-5VDC
8.2 Models SCM100ZJ-S1, 125ZJ-S1
