SRK22ZEV-S
END ITEM NO. : RWA002F045D
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-6 RKW102A200D PANEL ASSY,FRONT 1 1112
1 RKW122A200 PANEL,FRONT 1 1112
2 RKW435A200D PANEL ASSY AIR IN 1 1123
3 RKW437A200 FILTER,AIR 2 2248
4 RKW129A213 HOLDER,FILTER 2 1112
5 RKW133A202 FILM,CONCEAL 1 1112
6 RKW129A214 CAP 3 1112
7 RKW132A203 LID(TERMINAL) 1 1124
8-32 RKW435A202 GRILLE ASSY,AIR OUT 1 1123
8 RKW435A203 GRILLE,AIR OUTLET 1 1123
9 RKW436A200 FLAP(A) 1 1122Upper
10 RKW436A201 FLAP(B) 1 1122Lower
11⋅12
RKW436A202 LOUVER ASSY 1 1122R side
11 RKW436A203 LOUVER 6 1122
12 RKW129A209 PLATE,CONNECTING 1 1112
13⋅14
RKW436A202A LOUVER ASSY 1 1122L side
13 RKW436A203 LOUVER 6 1122
14 RKW129A209 PLATE,CONNECTING 1 1112
15 RKW935C200 COLLAR 8
16-23 RKW144A200 LINK ASSY 1 1112
16 RKW129A208 JOINT(L) 1 1112
17 RKW129A210 BRACKET,MOTOR ( A ) 1 1112
18 RKW144A201 LINK 1 1112
19 RKW144A202 CRANK(A) 1 1112
20 RKW144A203 CRANK(B) 1 1112
21 RKW144A204 CRANK(C) 1 1112
22 SSA512T045 MOTOR,STEPPING 1 1112For Louver (L)
23 SSA512T049 MOTOR,STEPPING 1 1112For Flap
24-27 RKW144A205 CRANK ASSY 1 1112
24 RKW129A207 JOINT(R) 1 1112
25 RKW129A211 BRACKET,MOTOR ( B ) 1 1112
26 RKW144A204 CRANK(C) 1 1112
27 SSA512T045 MOTOR,STEPPING 1 1112For Louver (R)
28 RKS504A100H HARNESS ASSY 1 1112For Flap motor
29 RKS504A100C HARNESS ASSY 1 1112
For Louver motor (R)
30 RKS504A100J HARNESS ASSY 1 1112
For Louver motor (L)
31 SSA423A094A HOSE,DRAIN 1
32 SSA326A041 PLUG 1
33 RKW111A200 BASE ASSY 1 1112
34 SSA512T072 MOTOR,DC 1 1112For Impeller
35 SSA431G043A IMPELLER 1 1124
36 SSA923C114 BEARING,PLANE 1 1112
37 RKW129A201 BRACKET MOTOR ( U ) 1 1112
NotePart Name RE.QNo. Part No.
- 209 -
