122
-
(c) Operation and setting from wired remote control
○：Correspondence
−：No function on remote control
Blank：Not compatible
△：Corresponding part
Setting
＆
display item Description RC-EX3
RC-E5
1.Remote control network
1 Control plural indoor units by a single remote control A remote control can control plural indoor units up to 16 (in one group of remote control network).
An address is set to each indoor unit.
○
2
Main/sub setting of remote controls A pair of remote controls (including optional wireless remote control) can be connected within the remote control
network. Set one to “Main” and the other to “Sub”.
○
○
2.TOP scrren, Switch manipulation
1 Menu "Control","State", or "Details" can be selected. (3-8) ○ −
−
−
2 Operation mode "Cooling","Heating","Fan","Dry" or "Auto" can be set. ○
○
3 Set temp. "Set temperature" can be set by 0.5˚C interval. ○
○
4 Air flow direction "Air flow direction" [Individual flap control] can be set.
Select Enable or Disable for the “3D AUTO” .
○
△
5 Fan speed "Fan speed" can be set. ○
○
6 Timer setting "Timer operation" can be set. ○
○
7 ON/OFF "On/Off operation of the system" can be done. ○
○
8 F1 SW The system operates and is controlled according to the function specified to the F1 switch. ○
9
F2 SW The system operates and is controlled according to the function specified to the F2 switch. ○
3.Useful functions
1
Individual flap control The moving range (the positions of upper limit and lower limit) of the flap for individual flap can be set.
2
Anti draft setting
When the panel with the anti-draft function is assembled.
When the panel with the anti draft function is assembled, select to Enable or Disable the anti draft setting for each
operation mode and for each blow outlet.
3 Timer settings Set On timer by hour The period of time to start operation after stopping can be set.
・
The period of set time can be set within range of 1hour-12houres (1hr interval).
・
The operation mode, set temp. and fan speed at starting operation can be set.
△
−
△
−
Set Off timer by hour The period of time to stop operation after starting can be set.
・
The period of set time can be set within range of 1hour-12houres (1hr interval).
○
○
Set On timer by clock The clock time to start operation can be set.
・
The set clock time can be set by 5 minutes interval.
・
[Once (one time only)] or [Everyday] operation can be switched.
・
The operation mode, set temp and fan speed at starting operation can be set.
△
○
Set Off timer by clock The clock time to stop operation can be set.
・
The set clock time can be set by 5 minutes interval.
・
[Once (one time only)] or [Everyday] operation can be switched.
○
○
Confirmation of timer settings Status of timer settings can be seen. ○
4 Favorite setting
[Administrator password]
Set the operation mode, setting temperature, air flow capacity and air flow direction for the choice setting operations.
Set them for the Favorite set 1 and the Favorite set 2 respectively.
○
5 Weekly timer On timer and Off timer on weekly basis can be set.
・
8-operation patterns per day can be set at a maximum.
・
The setting clock time can be set by 5 minutes interval.
・
Holiday setting is available.
・
The operation mode, set temp and fan speed at starting operation can be set.
○
○
6 Home leave mode
[Administrator password]
When leaving home for a long period like a vaction leave, the unit can be operated to maintain the room temperature
not to be hotter in summer or not to be colder in winter.
・
The judgment to switch the operation mode (Cooling
⇔
Heating) is done by the both factors of the set temp. and outdoor
・
The set temp. and fan speed can be set.
○
○ ○
7 External Ventilation
When the ventilator is combined.
On/Off operation of the external ventilator can be done.
It is necessary to set from [Menu]
⇒
[Service setting]
⇒
[R/C function settings]
⇒
[Ventilation setting].
・
If the “Independent” is selected for the ventilation setting, the ventilator can be operated or stopped.
8
Select the language Select the language to display on the remote control.
9
Look, look Indoor temperature, outdoor temperature and power consumption are indicated.
・
Select from English, German, French, Spanish, Italian, Dutch, Turkish, Portuguese, Russian,
Polish, Japanese and Chinese.
○
4.Energy-saving setting Administrator password
1 Sleep timer To prevent the timer from keeping ON, set hours to stop operation automatically with this timer.
・
The selectable range of setting time is from 30 to 240 minutes. (10 miuutes interval)
・
When setting is "Enable", this timer will activate whenever the ON timer is set.
○
−
○
−
2 Peak-cut timer Power consumption can be reduced by restructing the maximum capacity.
Set the [Start time], the [End time] and the capacity limit % (Peak-cut %).
・
4-operation patterns per day can be set at maximum.
・
The setting time can be changed by 5-minutes interval.
・
The selectable range of capacity limit % (Peak-cut % ) is from 0% to 40-80% (20% interval).
・
Holiday setting is available.
3 Automatic temp. set back After the elapse of the set time period, the current set temp. will be set back to the [Set back time.]
・
The setting can be done in cooling and heating mode respectively.
・
Selectable range of the set time is from 20 min. to 120 min. (10 min. interval).
・
Set the [Set back temp.] by 1˚C interval.
○
−
○
−
4
Infrared sensor control (Motion sensor control)
When the panel with the infrared sensor (motion sensor) is
When the infrared sensor (motion sensor) is used, it is necessary to set Enable or Disable for the “Power control”
and the “Auto-off”.
5.Filter
1
Filter sign reset
Filter sign reset The filter sign can be reset.
Setting next cleaning date
The next cleaning date can be set.
6.User setting
1
Internal settings
Clock setting The current date and time can be set or revised.
・
If a power failure continues no longer than 80 hours, the clock continues to tick by the built-in power source.
○
−
−
−
−
−
−
−
Date and time display [Display] or [Hide] the date and/or time can be set, and [12H] or [24H] display can be set. ○
Summer time When select [Enable], the +1hour adjustment of current time can be set. When select [Disable], the [Summer time]
adjustment can be reset.
○
Contrast The contrast of LCD can be adjusted higher or lower. ○
Backlight Switching on/off a light can be set and period of the lighting time can be set within the range of 5sec-90 sec (5sec interval). ○
Control sound It can set with or without [Control sound (beep sound)] at touch panel. ○
Operation lamp luminance This is used to adjust the luminance of operation lamp. ○
10
Power consumption indication The power consumption of today, this week and this year is indicated by a chart. It is possible to compare with
yesterday, last week and last year.
・This item may not indicate depending on indoor and outdoor units which are combined.
air temp.
assembled.
○
−
−
−
−
○ −
