Mitsubishi SRK25CES User Manual

-
176
-
(b) Dew condensation prevention control [Cooling (including automatic), cooling oriented dehumidifying operation]
(i) Operating condition: When the following conditions are met after 5 minutes or more of continuous operation after
operation starts.
• The humidity sensor value is 68% or higher
(ii) Operation contents
1) Command of the electronic expansion valve.
2) When such a command is continued for 30 minutes or more, air direction
controls will be as listed below:
Humidity (%)
63 68
Reset
Prevention control
(c) Indoor fan motor protection
When the air-conditioner is operating and the indoor fan motor is turned ON, if the indoor fan motor has operated at 300 rpm or
under for more than 30 seconds, the unit enters first in the stop mode and then stops the entire system.
Timer light illuminates simultaneously and the run light flashing 6 times at each 8-second.
(d) Three-minute forced operation
When the compressor begins operating the thermal operation is not effective for 3 minutes, so operation continues as is in the
operation mode. (After 3 minutes has passed the thermal operation is effective.)
However, stopping the compressor via a stop signal or protection control has priority.
(e) Abnormality of outdoor unit
When the indoor heat exchanger temperature does not fall to 25°C or below for 40 minutes after 5 minutes have elapsed since the
compressor operation start, the abnormality stop occurs. (The timer light flashes 2 times.)
(f) Compressor overheat protection
If the discharge pipe temperature (sensed by Th6) exceeds the set temperature value, the compressor stops. If the temperature is 95ºC
or lower after a 3-minute delay, it starts again, but if this function is reactivated again within 60 minutes, it results in an abnormal stop.
(Run light : ON, Timer light : 5 time flash)
(iii) Reset condition: When the following condition is satisfied.
• The humidity sensor value is less than 63%.
UP/ DOWN air scroll
Flap swing, UP/DOWN air scroll Executes the command to the left.
Situations besides the ones described above Controls the level of the UP/DOWN flap.
LEFT/ RIGHT air scroll
Louver swing, LEFT/RIGHT air scroll, Executes the command to the left.
Multi-directional Air Flow
Situations besides the ones described above Controls the front of the LEFT/RIGHT louver .
Discharge pipe temperature (˚C)
Operation possible
Abnormal stop
110
115
19 type: 95
25 type: 95
