SRK13ZEV-S
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-9 RKT301A506D HEAT EXCH ASSY 1 1112
2 RKT315D500 HEADER ASSY 1
3 RKT321A501A PIPE ASSY 1
4 RKT315A500 DISTRIBUTOR ASSY 1
5 RKT129A401 BRACKET(L) 1 1112
6-8 RKT321A500A PIPE ASSY 1
7 SSA323F082 UNION, SOLDER 1 For gas
8 SSA323F082A UNION(SLD) 1 For liquid
9 RKT129A402 PLATE, BAFFLE 1 1112
10 RKT142A600 BOX,CONTROL 1
11-13 RKT505A500DD PWB ASSY 1 2248
12 SSA555B050C VARISTOR 1 1112Z
13 SSA564A095 FUSE(CURRENT) 1 1124
14 SSA551A163F SENSOR ASSY 1 1124
Room temp&Heat exch. Sensor
15 SSA551B015 SENSOR(HUMIDITY) 1 1124
16 SSA561B675A BLOCK,TERMINAL 1
17 RKT503A600A DISPLAY ASSY 1 1123
18 RKT505A601A PWB ASSY(DISPLAY) 1 2248
19 RKJ941F001 SPRING,LEAF 1
For Heat Ex sensor
20 RKT008A510D PARTS,STANDARD 1
21 RMA502A003 CONTROL ASSY,REMOTE 1 2 3 5 10
22 RKT437A005C FILTER,LIGHT CLEAN 1 2248
23 RKT437A602 FILTER, CLEAN (ALLE) 1 2248
24 RKN032A002B HOLDER ( REMO-CON ) 1 1112
25 RMA012A005 MANUAL,INSTRUCTION 1
(26) RMA011F003Z LABEL,MODEL NAME 1
Part NO.No. Part Name RE.Q Note
- 207 -
