Mitsubishi SRK25CES User Manual

SRK22ZEV-S
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-9 RKW301A200A HEAT EXCH ASSY 1 1112
2 RKW315D204 HEADER ASSY 1
3 RKW129A200 BRACKET(L) 1 1112
4 RKW315A203 DISTRIBUTOR ASSY 1
5-7 RKW321A220 PIPE ASSY 1
6 SSA323F012F UNION, SOLDER 1 For gas
7 SSA323F082A UNION(SLD) 1 For liquid
8 RKW129A219 PLATE,ASSY BAFFLE ( R ) 1 1112
9 RKW129A220 PLATE,ASSY BAFFLE ( L ) 1 1112
10 RKW142A200 BOX,CONTROL ( R ) 1
11 RKW142A201 BOX,CONTROL ( L ) 1
12 RKW132A202 LID CONTROL 1 1124
13 SSA551A163L SENSOR ASSY 1 1124
Room temp&Heat exch. Sensor
14 SSA551B017 SENSOR (HUMIDITY) 1 1124
15 SSA561B702B BLOCK,TERMINAL 1 1122
16 SSA561B675C BLOCK,TERMINAL 2 1122
17 RKW011G200 LABEL WIRING 1
18-20 RKW505A200 PWB ASSY 1 2248
19 SSA555B050C VARISTOR 1 1112Z
20 SSA564A072 FUSE(CURRENT) 1 1112
21 RKW503A200 DISPLAY ASSY 1 1123
22 RKW505A202 PWB ASSY(DISPLAY) 1 2248
23 RKJ941F001 SPRING,LEAF 1
For Heat Ex sensor
24 RKW008A200F PARTS,STANDARD 1
25 RKW502A200 CONTROL ASSY,REMOTE 1 2 3 5 10
26 RKT437A005D FILTER,LIGHT 1 2248
27 RKT437A602B FILTER,CLEAN (ALLE) 1 2248
28 RKN032A002B HOLDER ( REMO-CON ) 1 1112
29 RKW012A209 MANUAL,INSTRUCTION 1
(30) RKW011F200P LABEL,MODEL NAME 1
No. Part Name RE.Q NotePart No.
- 213 -
