Page #219 background image
SRK10CES
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RKV301A500M HEAT EXCH ASSY 1 1112
2 RKV315D501 HEADER ASSY 1
3 RMA315A002 DISTRIBUTOR ASSY 1
4 RKV129A001 BRACKET(L) 1 1 1 1 2
5 RKV321A513 PIPE ASSY 1
6 SSA323F082 UNION(SLD) 1 For gas
7 SSA323F082A UNION(SLD) 1 For liquid
8 RKV129A004 PLATE,BAFFLE 1 1 1 1 2
9 RKV142A500 BOX,CONTROL 1
10 RKV505A500CJ PWB ASSY 1 2 2 4 8
11 SSA555B041B VARISTOR 1 1 1 1 2 Z
12 SSA564A072 FUSE(CURRENT) 1 1 1 1 2
13 SSA551A163F SENSOR ASSY 1 1 1 2 4
Room temp&Heat exch. Sensor
14 RKV504A500B HARNESS ASSY(POWER) 1 1 1 1 2
15 SSA561B713 BLOCK,TERMINAL 1 1 1 2 2
16 SSA554A441 TRANSFORMER 1 1 1 2 3
17 RKV503A100A DISPLAY ASSY 1 1 1 2 4
18 RKV505A100A PWB ASSY(DISPLAY) 1 2 2 4 8
19 RKJ941F001 SPRING,LEAF 1
For Heat Ex. Sensor
20 RKV142A501 COVER 1
21 RMA008A003C PARTS,STANDARD 1
22 RMA502A001 CONTROL ASSY,REMOTE 1 2 3 5 10
23 RKT129A009 HOLDER,FILTER 2 1 1 1 2
24 RKT437A602A FILTER,CLEAN 1 2 2 4 8
25 RKT437A005 FILTER,LIGHT CLEAN 1 2 2 4 8
26 RMA012A001B MANUAL,INSTRUCTION 1
(27) RMA011F003AA LABEL,MODEL NAME 1
NoteNo. Part No. Part Name RE.Q
- 217 -
