SRC22ZEV-S
END ITEM NO. : RWC003F048D
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RCR122A001 PANEL ASSY, FRONT 1 1112
2 RCR125A002 PANEL ASSY, REAR 1 1112
3 RCR124A002 PANEL,ASSY TOP 1 1112
4 RCR122A004 PANEL ASSY SERVICE 1 1112
5 RCR132A001 COVER,FRONT 1 1112
6 RCR115A001 SUPPORT,CORNER 1
7 RCR435A001 GRILLE,AIR OUTLET 1 1123
8 RCR132A004 COVER ASSY SERVICE 1 1124
9 RCR131A001 GUARD, FIN (A) 1 1112
10 RCR131A002 GUARD, FIN (B) 1 1112
11 SSA944B031A HANDLE 2
12 RCR132A002 COVER,TERMINAL 1 1124
13 RCR941G001 CUSHION 1
14 SSA913A034B SCREW,TAP 27
15 SSA913A034C SCREW,TAP 3
16 RCR116A001 BRACKET,MOTOR 1
17 SSA512T076 MOTOR,DC 1 2248
18 SSA913C021A SCREW,TAP 4
19 RCR141A00101 PLATE,BAFFLE 1
20 SSA431B247 FAN, PROPELLER 1 1124
21 SSA914B007AD NUT,TH 1
22 W011D04X008 TAP-SCREW,CRS-TRS 2 4
23 RCR111A001 BASE ASSY 1 1112
24 RCR011G001 LABEL, WIRING 1
NoteRE.QNo. Part No. Part Name
- 239 -
To Next Page
