Mitsubishi SRK25CES User Manual

SRC22ZEV-S
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-4 RCR301A001 HEAT EXCH ASSY(AIR) 1 1112
2 RCR321A046 PIPE ASSY 1
3⋅4
RCR321A056 PIPE ASSY 1
3 RCR315B008 CAPILLARY 1
4 RCR315B009 CAPILLARY 1
5 SSA382C078 VALVE, S(4WAY) 1 1112
6 RCR116A003A BRACKET(VALVE) 1
7 RCR381A003 VALVE,SERVICE(1/4" ) 1 1112LIQ.
8 RCR381A004 VALVE,SERVICE(5/8") 1 1112GAS
9-11 RCR304A008 PIPING ASSY (EXPAN) 1 1112
9 SSA387F035 VALVE,BODY(EXP) 1 1112
10 SSA357A005A STRAINER 2
11 RCP315B002 CAPILLARY,SUB 1
12 PCA325A007 PIPE,SHELL 1
13 AHT351A001 ACCUMALATOR ASSY 1
14 RCR154D004 INSULATION COMP 1
15 RPC154D858 INSULATION, COMP(B) 1
16 RPC382F700B COIL ASSY,SOLENOID 1 1112
17 SSA382F210L COIL,SOLENOID 1 1112
18 PCA201A048A COMPRESSOR ASSY 1 1238
19 PCA941C011 CUSHION,RUBBER 3
20 SSA914C013A NUT,FLANGE 3
21 PCA932C005 GASKET,COVER 1
22 PCA947K005 COVER,TERMINAL 1 1124
23 PCA914C001 NUT,FLANGE 1
24 RPC142A853 BOX,CONTROL(A) 1
25 SSA561B702B BLOCK,TERMINAL 1 1122
26 SSA561B665 BLOCK,TERMINAL 1 1122
27 SSA564A106B FUSE (CURRENT) 1 1112
28 SSA564B064 HOLDER, FUSE 1 1112
29 RCR504A009 WIRING ASSY 1 1112FOR COMP.
30 RCR505A001 PWB ASSY (MAIN) 1 2248
31 RCR505A002 PWB ASSY (POWER) 1 2248
32 RPC505A852B PWB ASSY (CAPACITOR) 1 2248
33 SSA551A207 SENSOR (TEMPERATURE) 1 1124
34 SSA554B079 REACTOR 1 1112
35 RKJ941F001 SPRING, LEAF 1
36 RCJ941F001 SPRING, LEAF 1
37 RPC008A601 PART STANDARD (B) 1
38 SSA422A024 ELBOW 1 2248
39 SSA947A089 GROMMET 2 1124
(40) RCR011F003F LABEL,MODEL NAME 1
NoteNo. RE.QPart No. Part Name
- 241 -
