Mitsubishi SRK25CES User Manual

SRC10CES
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RCP301A001H HEAT EXCH ASSY 1 1112
2 RCP321A001 PIPE 1
3 RCP321A035A PIPE 1
4-5 RMC304A002 PIPING ASSY 1 1112
4 RMC315B001 CAPILLARY 1
5 RMC315B005 CAPILLARY,SUB 1
6 RCK116A002 BRACKET(VALVE) 1
7 RMC381A001 VALVE,SERVICE(1/4" ) 1 1112For liquid
8 RMC381A002 VALVE,SERVICE(3/8" ) 1 1112For gas
9 RCG151C008B INSULATION,COMP 1
10 RMC201A002 COMPRESSOR ASSY 1 1238
11 SSA941C241 CUSHION,RUBBER 3
12 SSA914C013A NUT,FLANGE 2
13 SSA914C016 NUT,FLANGE 1
14 RSA947K005 COVER,TERMINAL 1 1124
15 RSA932C004 GASKET,COVER 1
16 SSA552A832 CAPACITOR,RUNNING 1 1112
17 SSA552A841 CAPACITOR,RUNNING 1 1112
18 RMC533B001 PROTECTOR,MOTOR 1 1112
19 AHA941D003 SPRING(PROTECTOR) 1
20 SSA561B713 BLOCK,TERMINAL 1 1122
21 RWC504A083A WIRING ASSY 1 1112For Compressor
(22) RMC011F002Z LABEL,MODEL NAME 1
NoteNo. RE.QPart No. Part Name
- 245 -
