Mitsubishi SRK25CES User Manual

SRC13CES
END ITEM NO. : RMC003F008
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RWC122A003 PANEL,FRONT 1 1112
2 RWC123A005 PANEL ASSY,SIDE(R) 1 1112
3 RWC123A002 PANEL,SIDE(L) 1 1112
4 RWC124A003 PANEL,TOP 1 1112
5 RWC132A007 PANEL ASSY, SERVICE 1 1124
6 RWC435A002 GRILLE,AIR OUTLET 1 1123
7 SSA944B036 HANDLE 1
8 RWC116A041 BRACKET,MOTOR 1
9 SSA511C063A MOTOR,AC 1 2248
10 RWC141A002 PLATE,BAFFLE 1
11 SSA947B019 GROMMET 1 1124
12 SSA431B233 PROPELLER 1 1124
13 SSA914B007AD NUT,TH 1
14 RWC111A003J BASE ASSY 1 1112
15 SSA913A034B SCREW,TAP 22
16 SSA913A034C SCREW,TAP 3
NoteRE.QNo. Part No. Part Name
- 247 -
