SRC13CES
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RWC301A022B HEAT EXCH ASSY(AIR) 1 1112
2 RWC321A373A PIPE ASSY 1
3 RWC321A374 PIPE ASSY 1
4-5 RMC304A005 PIPING ASSY(CAPI) 1 1112
4 RCP315B002 CAPILLARY,SUB 1
5 RMC315B003 CAPILLARY 1
6 RCK116A002 BRACKET(VALVE) 1
7 RCK381A501 VALVE,SERVICE(1/4" ) 1 1112
LIQ.
8 RWC381A012 VALVE,SERVICE(1/2" ) 1 1112
GAS
9 RCG151C021B INSULATION ASSY,COMP. 1
10 AHT201A345NN COMPRESSOR ASSY 1 1238
11 RSA932C004 GASKET,COVER 1
12 RSA947K005 COVER,TERMINAL 1 1124
13 SSA914C016 NUT,FLANGE 1
14 SSA941C239 CUSHION,RUBBER 3
15 SSA914C013 NUT,FLANGE 2
16 SSA552A834 CAPACITOR,RUNNING 1 1112
17 SSA561B669 BLOCK,TERMINAL 1 1122
18 RWC504A081C WIRING ASSY 1 1112For Compressor
(19) RMC011F002AA LABEL,MODEL NAME 1
NoteNo. RE.QPart No. Part Name
- 249 -
