Mitsubishi SRK25CES User Manual

SRC19CES
END ITEM NO. : RWC003F052B
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1 RWC122A003 PANEL,FRONT 1 1112
2 RWC123A005F PANEL ASSY,SIDE(R) 1 1112
3 RWC123A002 PANEL,SIDE(L) 1 1112
4 RWC124A003 PANEL,TOP 1 1112
5 RWC132A007 PANEL ASSY, SERVICE 1 1124
6 RWC435A002 GRILLE,AIR OUTLET 1 1123
7 SSA944B036 HANDLE 1
8 RWC131A004 GUARD,FIN 1 1112
9 RWC116A041 BRACKET,MOTOR 1
10 SSA511B817B MOTOR,AC 1 2248
11 RWC141A002 PLATE,BAFFLE 1
12 SSA947B019 GROMMET 1 1124
13 SSA431B233 PROPELLER 1 1124
14 SSA914B007AD NUT,TH 1
15 RWC111A003H BASE ASSY 1 1112
16 SSA913A034B SCREW,TAP 22
17 SSA913A034C SCREW,TAP 1
NoteRE.QNo. Part No. Part Name
- 251 -
