Mitsubishi SUZ-KA18NA2 User Manual

12
OCH688A
Representative matching PEAD-A30AA7 PEAD-A36AA7 SVZ-KP18NA SVZ-KP24NA
Item Unit Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Total
Capacity BTU/h 27000 30000 33000 33500 18000 21600 24000 25000
SHF – 0.84 – 0.84 – 0.85 – 0.81 –
Input kW 2.16 2.41 3.51 3.17 1.36 1.6 1.92 1.91
Electrical circuit
Indoor unit PEAD-A30AA7 PEAD-A36AA7 SVZ-KP18NA SVZ-KP24NA
Power supply (V, phase, Hz) 230, 1, 60 230, 1, 60
Input kW 0.17 0.15 0.25 0.23 0.16 0.18
Current A 1.31 1.2 1.71 1.6 1.44 1.6
Outdoor unit
SUZ-KA30
NA(H)2
SUZ-KA36
NA(H)2
SUZ-KA18
NA(H)2
SUZ-KA24
NA(H)2
Power supply (V, phase, Hz) 230, 1, 60 230, 1, 60
Input kW 1.99 2.26 3.26 2.94 1.2 1.44 1.74 1.73
Current A 8.08 9.28 13.55 12.18 4.47 5.52 6.75 6.70
Refrigerant circuit
Condensing pressure PSIG 419 417 456 356 369 349 411 415
Suction pressure
PSIG 147 105 142 97 144 100 145 108
Discharge temperature °F 164 162 176 176 158 158 156 167
Condensing temperature °F 120 120 127 108 111 108 116 119
Suction temperature °F 53 34 50 30 58 37 59 35
Ref. pipe length ft. 25 25
Refrigerant charge (R410A) – 2.2 1.6 2.2
Indoor
unit
Intake air temperature
DB °F 80 70 80 70 80 70 80 70
WB °F 67 60 67 60 67 60 67 60
Discharge air temperature DB °F 58 98 57 95 58 100 59 96
Outdoor
unit
Intake air temperature
DB °F 95 47 95 47 95 47 95 47
WB °F 75 43 75 43 75 43 75 43
