Mityvac MV4530 - Page 2

Service Parts
Part Number Description
823037 Pressure Pump w/ Gauge
823042 Adapter Wrench
823043 Plug and Tether
823046 Deep Neck Adapter
MVA100 O-Ring and Washer, MVA101 O-Ring
823047 and Washer, MVA102 O-Ring and Washer,
MVA103 O-Ring and Washer
823051 Custom-Molded Case
Page Number - 2 Form 823916
823042
823037
823046823043
823051823047
Table of Contents
Service Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Schematics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Applications and Basics of Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Static Pressure Test (Engine Off) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dynamic Pressure Test (Engine On) . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cap Pressure Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
