HARDWARE IDENTIFIER
H1 - M6 x 28mm
Allen Head Bolt (8)
H2 - 6 x 15 mm
Flat Washer (8)
H3 - M8 x 28mm
Allen Head Bolt (12)
H4 - 8.5 x 19mm
Flat Washer(12)
(Not To Scale)
(To Scale)
PARTS IDENTIFIER
P1-Pool Table
Cabinet(1)
P2-Right Leg(2) P3-Left Leg(2)
P4-End Leg Panel(2)
P5-Side Leg Panel(2)
P6-Leg Leveler(4)
T1 - Allen Wrench(1)
(Not to Scale)
H5 - M4 Lock
Nut (12)
H6 - 4 x 22mm
Phillips
T2 - Wrench(1)
(Not to Scale)
Round Head Bolt (12)
