STEP 9:
14
©
2012 Escalade Sports
For Customer Service Call 1-866-556-2757
With the help of three other adults, carefully rotate the rail and apron assembly and then place over the
play bed as shown. From the underside of the table, insert each H12 Bolts with H13 Washers up through
the play bed and into the threaded inserts of each rail. Be sure the rail assembly is aligned with the
play bed and pockets, then tighten all bolts.
H13
H12
H13
H12
Figure 17
PARTS REQUIRED:
18 pcs - H12 Bolt
18 pcs - H13 Washer
