Using the battery charger battery charger
12
➤ Connect the black minus clamp of the battery charger to the negative pole
(-) of the battery (see Fig. 7, page 3).
➤ Now plug the mains plug into an earthed and properly fuse-protected
240-V mains socket.
If you are uncertain, consult a specialist.
✓ The ammeter (Fig. 8 E, Page 3) points to “Start”.
➤ Determine whether you are starting a vehicle with a 12-V or 24-V battery.
➤ Set the A switch (Fig. 8, page 3) to
– 12-V battery
– 24-V battery
✓ You can now start the vehicle.
Unclamping the battery charger
Caution!
When unclamping the battery charger, make sure not to cause a
short-circuit.
➤ When the starting procedure is finished, pull the 240-V mains plug from
the socket.
➤ Unclamp the black minus clamp of the battery charger.
➤ Unclamp the red plus clamp of the battery charger.
