7
8
Slide panel [27] into the back panels [6] and [11].
Slide panel [28] into the back panels [6] and [8].
Attach 8x wedge (J) to panel [13] with a hammer and secure with 8x
screw (D).
Attach panel [23] to panel [13] with 1x screw (C).
Tighten all screws with a screwdriver.
86
11
27
28
13
J
23
C
D
D
D
D
D
D
D
D
J
J
J
J
J
J
J
5
6
Attach panel [8] to panel [9] with 2x screw (A).
Tighten all screws with a screwdriver.
Attach panels [6] and [11] to panel [9] with 4x screw (A).
Tighten all screws with a screwdriver.
A
A
8
9
9
6
11
A
A
A
A
Mocka Kitchen
5
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
