Modern Forms Axis 52 - Page 15

FR-W1803-52 Axis Instructions 15
2C
2D
1
2
2
1
3
9
8
7
5
6
4
1. Hanger Ball/
Mounting Bracket
2. Downrod
3. Canopy
4. Canopy Screw Cover
5. Coupling Cover
6. Collar
7. Cotter Pin
8. Clevis Pin
9. Screws
1. Wood Screw
2. Safety Cable
HARDWARE USED:
B - Wood screw, spring washer,
and flat washer
