20FR-W1803
13. WALL CONTROL OPERATING INSTRUCTIONS (cont.)
FIGURE 22
FIGURE 23
NOTE: Maximum of 2 fans can operate on a circuit through the wall
transmitter.
Maximum of 12 fans can operate on a circuit through an on/o switch
or breaker when utilizing the app for the fan control (without the
wall transmitter in the circuit).
Summer mode - (Counter-clockwise) A downward airow creates a cooling
eect as shown in Fig. 22. This allows you to set your air conditioner on a
warmer setting without aecting your comfort.
Winter mode - (Clockwise) An upward airow moves warm air o the
ceiling area and redistributes the warm air that hovers around the ceiling to
the living space as shown in Fig. 23. This should allow for savings on heating
costs.
NOTE: To operate the reverse function on this fan, press the reverse button
while the fan is running.
NOTE: Fans do not change the temperature in the room, they change the
comfort level allowing you to save energy.
