Modulex MSP-080F - Page 2

LightingFixture
ToinstallModuleXsafety
MSP-080F/20A/DL/3
InstallationDetails InstallationDiagram
Caution
Cutoutaholeandinstallthe
mountingframe
Mountingframe
1
Installthemountingequipment
forceilingcutout
Slidethemetalfittingsfromupper
side
Onstep2,pleasefixthemetal
fittingfirmlywithyourfingers.
Ifnot,itmaycausefallingoffixtures
Metalfitting
Ceilingcutout
Useascrewdriverandtightenthe
metalfittings
1
2
2
3
a
a b
b
3
Standardtoscrew
torque1.0〜2.0N・m
Pushtight
Φ82
Makesuretotightenthemetal
fittingssecurelywithascrewdriver.
(torque1.0〜2.0N・m)Ifitisloose,
itmaycausefallingofthefixture
Ceiling
Wiringconnection
Pleaseconnectaccordingto
thedescriptionofapowersupply.
InstallationGuide
Installationtoceiling
h
i
h
Installthefixturetothemounting
frame.
Installthesafetywiretothe
mountingframe.
Makesuretoinstallthesafetywire
tothemountingframesecurely.
Makesurethefixturewillnottouch
anyobjectsinceiling.
1
2
i
Usecleansoftclothtocleanupand
maintaininnersideofthebody.
1
2
Safetywire
Ceiling
Mountingframe
Safetywire
Inside
Cleangloves
SLICKJIAKARI
Wiringdiagram
PE
PE
L
L +
+RED
-BLACK
-
N
N
DC700mAMAX
LED
Driver
35.6V
LongbowHouse,14-20ChiswellStreet,London,EC1Y4TW,U.K
Tel:+44-01273-616649
HavellsSylvaniaEuropeLtd.
（Contact） （Manufacturer）
ModuleXInc.
#21AraiBldg,1-20-6Ebisu-MinamiShibuya-ku,Tokyo
Tel:+81-3-5768-3131
Whenconnectingthedriver,
carefulattentionshouldbe
paidtoconnecting＋and−.
Metalpartinacablepoint,
pleasedon'ttouchwithbare
handdirectly.
CAUTION！
Donotreversepolarity！
−BLACK
＋RED
