USA Ed. 1116
2 • INSTALLATION INSTRUCTIONS
2.1 • TECHNICAL DATA
Model Type
Rated
voltage
[Vac]
Total power
consumption
[kW]
Consumption
[A]
Cable according to IEC-
60245-57 (H05RN-F or
HO7RN-F). Minimum
cross section of con-
nection cable (AWG)
Water
pressure
kPa
[Psi]
GCE060D GCE060D
3AC 208V
5,2 14,5 4 x 15
150 ÷ 500
[21,7 ÷ 72,5]
GCE061D GCE061D 7,7 21,5 4 x 13
GCE106D GCE106D 7,7 21,5 4 x 13
GCE101D GCE101D
3AC 480V
15,4 18,6 4 x 13
GCE110D GCE110D 15,4 18,6 4 x 13
Model Type
Operating
temperature
°C [°F]
Tray
capacity
Maximum pro-
duct load for a
h40 tray
kg [lb]
Maximum total
load of food +
tray
kg [lb]
Weight
when empty
kg [lb]
GCE060D GCE060D
30 ÷ 280
[86 ÷ 536]
6 GN 2/3 1,6 [4] 10 + 6 [22 + 13]
GCE061D GCE061D
6 GN 1/1 o
600x400
2,4 [5] 15 + 9 [33 + 20]
GCE106D GCE106D 6 GN 1/1 2,4 [5] 15 + 9 [33 + 20]
GCE101D GCE101D
10 GN 1/1 o
600x400
2,4 [5] 24 + 15 [53 +33]
GCE110D GCE110D 10 GN 1/1 2,4 [5] 24 + 15 [53 +33]
2.2 • INSTRUCTIONS FOR POSITIONING
unipotential system
2.3 • INSTRUCTIONS FOR ELECTRICAL CONNECTION AND UNIPOTENTIAL SYSTEM
