MODZ Max Series - Charger Status Indicator Light; Charging States; Fault Status

11 | ®
The MODZ® Max charger features an easy-to-read led charging status
indicator light.
CHARGING STATES
Charging Mode
Battery Level
Charging State Indicators
Trickle Charging
0% - 20%
Red flashing: On 1 second, Off 3 seconds
Low Battery Charging
20% - 80%
Red flashing: On 1 second, Off 1 second
Normal Charging
80% - 99%
Yellow flashing: On 1 second, Off 1 second
Fully Charged
100%
Solid green light
Fault Status
If the charger status light is flashing green and red it may be due to one
or more of the following reasons:
Possible Fault Reason
Recommendation
No or insufficient load
Ensure the charger plug is fully plugged into the charging receptacle
and that there are no dead or defective batteries via a load test
Over voltage or current
Unplug the charger from both the golf cart and the power outlet,
after several minutes attempt to reconnect the charger
The ambient
temperature is too high
Confirm the ambient temperature is not in excess of 149F and the
charger has proper ventilation
The ambient
temperature is too low
Confirm the ambient temperature is not below -22F
Input AC abnormality
Check the input voltage and confirm the AC plug is in good
condition
