OR
8
6
7
Run the free end of the coaxial cable from the mounting location to the
location of the TV. Connect the coaxial cable to the connector on the power
injector. If needed, coaxial cable can be added with a coaxial coupler (not
provided). Excessive cable may cause reception loss.
Connect the coaxial cable attached to the power injector
to the ANT/IN connector on the back of the TV.
NOTE: If using an RF splitter, turn to the next page
and follow the RF splitter installation instructions.
The power injector must be
powered in order to
function. Plug the
amplifier’s USB cable
into an open USB port
on the back of the TV.
If the TV does not have
a USB port, use the
included power adapter
to power the power injector
via any standard 120V
wall outlet.
Place the u-bolt under the bottom toothed
plate, and secure the plate with the four
included screws and washers to the antenna.
Sandwich the mounting tube between the
bottom and top toothed brackets and secure
with the included wingnuts.
Insert the short end of the mounting tube
into the mounting bracket.
Use the two Carriage bolts and washers to
secure the mounting tube to the
mounting bracket.
INSTRUCTIONS
Power
Injector
USB Cable (attached)
Coaxial
Cable
(attached)
ANT/IN
Back of TV
a. TV’s USB Port
b. Wall Outlet
POWER OPTIONS:
2
3
4
5
A
B
Select mounting location, ideally wood
framework (in attic) or outside (roof / siding).
A Position the mounting bracket (flat surface
to wood ) to create an “
” shape when
viewed from straight on.
B Secure the mounting bracket by using the
four large outdoor screws.
1
Attach end of the 30 ft. coaxial cable to the connector on the antenna.
