Monacor TXA-800PS - Operation; Specifications

7
English
3 Operation
1) Connect the power supply unit provided
to the jack DC IN, located on the side of
the charging station, and to a mains socket
(230 V/ 50 Hz). Thus, the charging station is
switched on.
2) After switching on, the charging station
will perform a short self-test: at each charg-
ing compartment, the LEDs OK and ON will
briefly light up in succession. After comple-
tion of the self-test, the LEDs ON will briefly
light up once again: the charging station is
now ready for operation.
3) Insert the units (TXA-800HSE or TXA-800R)
with their batteries into the charging com-
partments.
4) During the charging process, the orange
LED ON of the corresponding charging com-
partment will light up. (If the LED flashes,
the batteries are not correctly inserted into
the transmitter /receiver or non-rechargea-
ble batteries are used instead of rechargea-
ble batteries – in this case, remove the unit
from the compartment immediately.)
5) When the batteries of a unit have been
fully charged, the green LED OK of the
corre sponding charging compartment will
light up. The unit can be removed.
6) To switch off the charging station, discon-
nect the power supply unit from the mains
socket. The LEDs ON will briefly light up.
Note: When the charging station is disconnected
from the power supply, allow the unit to reset for
5seconds before operating it again.
Never put defective rechargeable
batteries in the household waste;
always take them to a special waste
disposal, e. g. collection container at
your retailer.
4 Specifications
Charging method: . . pulse charging with
∆Vand timer control
Charging current:
. . 450 – 500 mA
Charging time:. . . . . approx. 3 – 4 hours
for NiMH batteries
1300 mAh
Ambient
temperature:
. . . . . . 0 – 40 °C
Power supply: . . . . .
⎓
12 V/ 500 mA via
power supply unit
provided and connected
to 230 V/ 50 Hz
Dimensions:. . . . . . . 105 × 62 × 83 mm
Weight: . . . . . . . . . . 166 g
Subject to technical modification.
All rights reserved by MONACOR
®
INTERNATIONAL
GmbH & Co. KG. No part of this instruction manual
may be reproduced in any form or by any means for
any commercial use.
