Mondraker Dune - Page 4

26
Dune Carbon XR
A
B
C
D
E
F
G
H
I
J
K
L
M
380mm
580mm
-18/+3mm
353mm
445mm
73,6º
77.1°
63.6º
44mm
1236mm
100mm
440mm
625mm
450mm
625mm
-18/+3mm
353mm
445mm
73,6º
77.1°
63.6º
44mm
1289mm
130mm
480mm
652mm
490mm
650mm
-18/+3mm
353mm
445mm
73,6º
77.1°
63.6º
44mm
1313mm
140mm
500mm
662mm
420mm
600mm
-18/+3mm
353mm
445mm
73,6º
77.1°
63.6º
44mm
1260mm
110mm
460mm
634mm
S M L XL
DUNE
Manuals & Documents
EN
1. DIMENSIONS
Seat Tube Length
Top Tube Length
Bottom Braket Drop
Bottom Braket Height
Chainstay Length
Seat Tube Angle, Actual
Seat Tube Angle, Eective
Headtube Angle
Fork Oset
Wheelbase
Headtube Length
Reach
Stack
FRAME SIZE
