Mongoose M60S - WIRING INFORMATION; MAIN MODULE WIRING

WIRING INFORMATION:
Installation to
be carried out by suitably qualified persons.
MAIN MODULE
The plugs are edge numbered & the
wires printed for the function;
1)
–
TRIG
(
-
) BONNET & BOOT
TRIGGER INPUT
2)
CH2
(
-
) CH 2 OUTPUT
–
EG: BOOT RELEASE
3)
IGN
(+) 12v IGNITION INPUT
4)
GND ARM
GROUND WHEN ARMED
5)
DOOR
(
-
) DOOR TRIGGER
–
jumper changes polarity
6)
NO CONNECTION
10) FLASHER
(+) INDICATOR OUTPUT
–
8 amp cont’ max
11) 12V
(+) CO
NSTANT 12v POWER SUPPLY
12)
FLASHER
(+) INDICATOR OUTPUT
–
8 amp cont’ max
13) & 14) GND
(
-
) 2 GROUNDS
–
DO NOT JOIN TOGETHER AT THE SAME POINT
15)
SIREN
(+) SIREN OR HORN OUTPUT
7)
WHITE
LOCK
-
NC
8)
ORANGE
UNLOCK
–
NO
9)
BLUE
UNLOCK
–
COMMON
16)
PURPLE
LOCK
–
NO
17)
BROWN
UNLOCK
-
NC
18)
GREEN
LOCK
-
COMMON NOT USED
IM01
IMMOBILISER CIRCUIT #1
–
PAIRED WIRES
–
max 20amp cont’
IM02
IMMOBILISER CIRCUIT #2
–
PAIRED WIRES
–
max 20 amp cont’
