Mongoose REACT E4 - Attaching the Handlebar; Adjusting Handlebar Height

10
Adjusng Handlebar HeightAaching the Handlebar
❶ Place the handlebar in the center of the boom handlebar
clamp.
❷ Hook the back of the top clamp plate into the back of the
bottom plate. Rotate the clamp until the holes are aligned.
❸ Insert the bolt into the hole on the top handlebar clamp and
tighten the bolt.
❶ Release the quick release lever.
❷ Adjust the handlebar tube up and down to the desired height
(there are three lock in posions to choose from).
❸ Lock the quick release lever.
❷
❸
❶
❶
❷
Three
height
posions
