3.Then place 2 pcs AAA (LR03) batteries in the compartment, make sure that you observe the respective polarity (+/-) when
you place them, it is indicated on the bottom of the compartment.
4.Replace the cover of the battery compartment and secure it with the screw.
5.The batteries must be handled by an adult. Do not allow the children to play with the batteries.
6.Warning! The placing of the further change of the batteries must be done by an adult.
II. Buttons of the remote control – See Figure RC:
- F - Forward - press to move the SUV forward;
- B - Back - press to move the SUV backwards;
- R - Turn right - press to turn the SUV to the right;
- L - Turn left - press to turn the SUV to the left;
- Brake – to stop the SUV from moving;
- Match code – to connect the RC to the SUV;
- Downshift – switch for low speed;
- Upshift – switch for high speed;
- Rock/ Sport – switch for swinging or moving the SUV;
- Horn ;
-- Music Next;
- Music & Lamp Switch;
- ON/ OFF – to power ON or OFF the SUV;
III. Connect the RC to the SUV.
1.Make sure that you have placed batteries in the compartment of the RC.
2.Turn off the power of the SUV.
3.Press the ON/ OFF button to turn on the RC. The first LED light will lit up. Hold the ON/ OFF button for about 3 seconds to
turn off.
4.Hold the Match code for 3 seconds. The LED lights will start to flicker. Turn on the power of the SUV. The then the LED
lights will lit up. This means the connection was successful.
IV. USE OF THE RC:
1.This device has a memory function. This means that when you change the old batteries with new ones, there will be no
need to reconnect the RC to the SUV.
2.Press the buttons upshift and downshift to control the speed with which the SUV is moving.
3.Press the F, B, L and R buttons respectively for moving forward, backward, turning left or right.
4.Press the Brake button to stop the SUV from moving. All the LED lights will flicker. Press again the button to release the
SUV and it to start moving.
5.Press the Rock/ Sport button for swing function or moving.
6.Press the Music & Lamp Switch button to turn on or off the melodies and lights.
7.Press music next to hear the next song/ melody.
NOTE: If you do not use the RC for 10 seconds, it will turn off automatically.
Moni Trade Ltd., hereby, declares that this type of radio equipment model LBB-985 complies with Directive
2014/53/EC. The complete text of EC declaration for compliance can be found at the following Internet address:
www.moni.bg.
V. IMPORTANT INFORMATION ABOUT THE BATTERIES:
1. Always remove the discharged batteries and do not throw them away with the household waste, use the places
designated for that purpose. They are recyclable.
2. Use only batteries with the size and voltage, marked on the bottom of the battery compartment.
3. Alkaline batteries are recommended.
4. Always remove the batteries, if you will not use the product for a long period of time.
5. When you replace the batteries always replace them with new ones, always replace all batteries. Children should not be
present while you are replacing the batteries.
6. Do not mix old batteries with new ones.
7. Do not mix alkaline, standard (Carbon - Zinc), or rechargeable (Nickel – Cadmium) batteries.
8. Do not throw the batteries in fire, because they may blow up or leak.
17
FUSE
See Figure F. The battery is connected to a self resetting fuse. If the electric system or the battery are overloaded, the fuse
will turn off the electric supply in the SUV. It will restart after 5 - 10 seconds. Then the SUV can be used again. If the fuse is
repeatedly tripping, then the SUV probably should be repaired. Contact the shop, from which you bought the product. DO
NOT TRY TO REPAIR THE PRODUCT BY YOURSELVES, BECAUSE YOUR WARRANTY WILL EXPIRE.
Follow the rules bellow to avoid tripping of the fuse:
•Do not overload the SUV.
•DO NOT tie anything behind the SUV.
•DO NOT drive up steep slopes.
•DO NOT drive into fixed objects, as this causes the wheels to spin, leading the motor to overheat.
•DO NOT drive in very hot weather as the components may overheat.
•DO NOT allow the access of water or other liquids to the battery or other electric components.
•DO NOT tamper with the electric system. This may cause short circuit.
