v1.05
6.26.09
- 33 -
Monico
Id
PID Description Modbus
Address
Manual Remarks
239 Warning Status 30239 Each of the first 24 bits represents warning status.
0 = Warning is NOT ACTIVE
1 = Warning is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
240 Shutdown Status 30240 Each of the first 24 bits represents Shutdown status.
0 = Engine Shutdown is NOT ACTIVE
1 = Engine Shutdown is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
bit 5 = Low engine coolant temperature
bit 6 = High engine coolant temperature
bit 7 = Low engine oil pressure
bit 8 = High system voltage
bit 9 = High engine inlet air temperature
bit 10 = High engine oil temperature
bit 11 = High hydraulic oil temperature
bit 12 = No coolant flow
bit 13 = High aftercooler coolant temperature
bit 14 = High crankcase pressure
bit 15 = Fuel filter plugged
bit 16 = Oil filter plugged
bit 17 = Not used
bit 18 = Not used
bit 19 = Low coolant level
bit 20 = Alternator NOT charging
bit 21 = Low fuel level
bit 22 = High transmission oil pressure
bit 23 = Low transmission oil pressure
bit 24 = High transmission oil temperature
bit 25-32 = Not used
241 Engine Derate Status 30241 Each of the first 24 bits represents Eng. Derate status. 0 =
Engine Derate is NOT ACTIVE
1 = Engine Derate is ACTIVE
bit 1 = High exhaust temperature
bit 2 = High altitude (atmospheric pressure)
bit 3 = Air filter plugged
bit 4 = Engine overspeed
