v1.05
6.26.09
- 35 -
Monico
Id
PID Description Modbus
Address
Manual Remarks
active; 10 = Undefined; 11 = Not available, or not installed.
bits 1-2 = Underfrequency
bits 3-4 = Overfrequency
bits 5-6 = Undervoltage
bits 7-8 = Overvoltage
bits 9-10 = Generator Frequency Sensing Fault
bits 11-12 = Generator Total Overcurrent
bits 13-14 = Single Phase Overcurrent
bits 15-16 = Reverse Power
bits 17-18 = Undefined, future use
bits 19-20 = Undefined, future use
bits 21-22 = Undefined, future use
bits 23-24 = Generator Freq. Inconsistent w/Eng Speed
bits 25-26 = Undefined, future use
bits 27-28 = Undefined, future use
bits 29-30 = Undefined, future use
bits 31-32 = Undefined, future use
260 High Exhaust Port Temp Deviating Low Warning 30260 Status indicated by bits. 0-4294967295 is Valid Range. Each
of the first 24 bits represents warning status.
0 = Warning is NOT ACTIVE
1 = Warning is ACTIVE
bit 1 = Exhaust Temperature Deviating Low
bit 2 = Exhaust Temperature Deviating High
261 High Exhaust Port Temp Deviating Low Shutdown 30261 Status indicated by bits.
0 = Shutdown is NOT ACTIVE
1 = Shutdown is ACTIVE
bit 1 = Exhaust Temperature Deviating Low
bit 2 = Exhaust Temperature Deviating High
