F1 - MONO CONSTANT (FACTORY SET AT 210)
F2 - TOP HEAT GAIN (FACTORY SET AT 50)
F3 - BOTTOM HEAT GAIN (FACTORY SET AT 50)
F4 - FRONT TOP ELEMENT OFFSET VALUE (0-50) (FACTORY SET AT 25)
F5 - DEG “C”, DEG”F”
F6 - “2 MINUTE FROM END OF BAKE ALARM (ENABLE=1,DISABLE=0)
F7 - PRE-STEAM - (ENABLE=1, DISABLE=0)
F8 - STEAM - (ENABLE=1, DISABLE=0)
F9 - BAKE TEMPERATURE OFF-SET (+ - 25 DEG C)(set to –10)
F10 - MAXIMUM SET TEMPERATURE LIMIT (250 DEG “C” DEFAULT)
MAXIMUM TEMPERATURE 290 DEG “C”
F11 - BAKE CONTROLS LOCKOUT – (ENABLE=1, DISABLE=0)
(TO PREVENT OPERATOR CHANGING SET BAKE PARAMETERS)
F12 SLEEP MODE DELAY TIME - 60 MINUTES MAX. 0 = DISABLED
F13 - INTERIOR LIGHT AUTO-TIMEOUT - ON/OFF.
BETWEEN 1 AND 20 MINUTES (0 = disabled)
F14 - 0-9 PROGRAMS
Sets the number of programs available to the operator
F15 - 7 DAY TIMER - (ENABLE=1, DISABLE=0)
IF ENABLED, “SET BAKE” TIME ACTS AS EXTRA TIME BUTTON.
IF DISABLED, “AUTO ON SET” ACTS AS EXTRA TIME BUTTON.
F16 - 8 HOUR COUNT DOWN TIMER - (ENABLE=1, DISABLE=0)
AFTER 8 HOURS THE OVEN WILL TURN OFF (NOT DURING A BAKE
CYCLE).
BEFORE SWITCH OFF, DISPLAYS WILL FLASH AND ALARM WILL
SOUND. IF ANY BUTTON IS PRESSED AT THIS TIME, AN HOUR WILL
BE ADDED TO THE TIMER.
F17 - LAMP OUTPUT SOFT START - (ENABLE/DISABLE)
F18 - STEAM TYPE - (PLATE = 0, TROUGH = 1)
F19 - STEAM TARGET TEMPERATURE - (50 – 250 DEG C)
After switching on the controller, before the sleep delay time is initiated (if enabled in F12), the set bake
temperature must be reached, steam recovery time elapsed and a bake cycle started and stopped.
Once the stop bake button (2) has been pressed at the end of a bake, the sleep delay timer counts down until it has
timed out. At this point the controller switches into sleep mode (SLP displayed in temperature window) and the
oven will drop to a pre-set fall back temperature of 170 deg c, which it will maintain.
Note – damper closes when oven goes into sleep mode.
Pressing any button during the sleep mode delay time will not affect the countdown, apart from the O/I button
which switches the controller off. Pressing the start/stop bake buttons will reset the countdown timer.
Pressing any button while in sleep mode (apart from lights on/off(4) – which operates as normal and the panel
O/I on/off(1), which will turn the controller off) will bring it out of sleep mode, at which point the oven will heat up to
its previous set bake temperature (typical recovery time from 170 deg c to 230 deg c is 15 minutes approx)
Note – if no buttons on the controller are pressed after exiting sleep mode, the controller will switch back into sleep
mode, after the sleep delay time has expired.
