Installation and Operation Manual Eco Convection Ovens | 4/5/7/10-Tray | Steam
FG1BX-UK-MAN-0100 | Rev. C23 (July 2023) MONO
51
Figure 12: 10-Tray Motors and Elements (FG150)
Table 5: Item numbers in Figure 12
Item Number Part Number Part Description
TB3 N/A Motor and Element Connections
21 B888-30-014 Overheat thermostat
NOTE
Part numbers are referenced from electrical drawing M1500E25-75100 in the Electrical Manual.
