Installation and Operation Manual Eco Convection Ovens | 4/5/7/10-Tray | Steam
FG1BX-UK-MAN-0100 | Rev. C23 (July 2023) MONO
75
Part 4 | Section 1 | Motor and Element (FG153)
Figure 33: Motor and Element (FG153)
Table 23: Item numbers in Figure 33Figure 26
10 B720-74-005 Fan motor unit
11 B847-04-067 Heating element, 240 Vac
B847-04-074 Heating element, 220 Vac
NOTE
Part numbers are referenced from electrical drawing M158E25-75200 in the Electrical Manual.
