Mono FG149

MONO Bx Eco-connect Ovens 4/5/10-Tray | Steam Installation and Operation Manual
72
MONO FG0BX-UK-MAN-0200 | Rev. A21 (July 2021)
PART 2 / SECTION 5 – 4/5 TRAY 18 X 30 BAKING CHAMBER AND DOOR PARTS
LH FIXED RUNNERS 4 TRAY
PT No.159-01-05000
LH FIXED RUNNERS 5 TRAY
PT No.159-01-05200
REAR SHEET
PT No.159-01-10900
TOP HINGE LH OVEN PT No.158-03-10501
TOP HINGE RH OVEN PT No.158-03-10500
BOTTOM HINGE LH OVEN PT No.158-03-10500
BOTTOM HINGE RH OVEN PT No.158-03-10501
DOOR SEAL
PT No.159-03-01500
INNER DOOR
INCLUDING GLASS
PT No.159-03-10200
FAN
PT No.150-00-11300
OUTER DOOR GLASS
PT No.159-03-04200
RH FIXED RUNNERS 4 TRAY
PT No.159-01-05001
RH FIXED RUNNERS 5 TRAY
PT No.159-01-05201
COMPLETE DOOR ASSEMBLY = PT No 159-03-04000 = LH HINGE DOOR
PT No 159-03-04001 = RH HINGE DOOR
HANDLE/ CATCH ASSEMBLY
PT No.
A
900-27-118
DOOR SWITCH
PT No.B842-07-037
FG159
