MONO Bx Eco-connect Ovens 4/5/10-Tray | Steam Installation and Operation Manual
84
MONO FG0BX-UK-MAN-0200 | Rev. A21 (July 2021)
PART 4 / SECTION 2 – 4/5 TRAY 40 X 60 – MAIN PANEL
PART 27
FAN FUSE
B842-85-025
PART 3
CONTROL CIRCUIT MCB – B872-22-062
PART 28
AUX SOCKET FUSE
B842-85-039
PART 25
LIGHT FUSE
B842-85-042
PART 22
OVERHEAT THERMOSTAT
B888-30-014
PART 1
POWER SUPPLY
B801-93-005
PART 8
ELEMENT CONTACTOR
B801-08-021
PART 7
FAN MOTOR REVERSE CONTACTOR
B801-08-031
PART 6
FAN MOTOR FORWARD CONTACTOR
B801-08-031
PART 5a
FAN MOTOR OVERLOAD UNIT
B801-03-020
PART 5b
FAN MOTOR OVERLOAD AUX CONTACT
B801-14-012
PART 2a
LIGHT RELAY
B723-37-004
PART 2b
LIGHT RELAY BASE
B723-36-001
TB1
TB2
TB3
PART NUMBERS REFER TO DRAWING M158E25-75200 IN ELECTRICAL MANUAL
