MONO Bx Eco-connect Ovens 4/5/10-Tray | Steam Installation and Operation Manual
70
MONO FG0BX-UK-MAN-0200 | Rev. A21 (July 2021)
PART 2 / SECTION 4 – 4/5 TRAY 18 X 30 – WATER/STEAM SYSTEM
WATER INLET ASSY (INC. HOSE)
158-17-00400
PART 12
COPPER PIPE
A900-34-253
(10mm OD X 20 swg)
PART NUMBERS REFER TO DRAWING M159E25-75000 IN ELECTRICAL MANUAL
HOSE – BLUE
A900-34-087
BULKHEAD COUPLING
A900-34-321
(UNDER INSULATION)
