Eco Convection Ovens | 4/5/7/10-Tray | Steam Quick Start Guide
16
MONO FG1BX-UK-QSG-0100 | Rev. B23 (July 2023)
Touchscreen Operations
Operations are performed by touching an area of the screen, bringing up the next information panel, or
activating a function.
CAUTION Do not use excessive force to operate the touchscreen panel.
Figure 4: Main screen
Callout Function Purpose of the function
A Home
Return to Home screen.
B Settings Access to oven settings.
C Sleep Sleep mode – see page 30.
D Standby Standby mode – see page 30.
E Save Save the settings.
F Program title It shows the current program.
G Timer Timer for general use.
H Damper Damper control.
I Start Starts a baking program.
J Steam Steam control.
K Temperature Oven temperature control.
NOTE: The images are for illustration purposes and may differ from your oven.
