Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
38-31-09
Page 712
Feb 23/04
(f) Install connector (45) using screws (50), washers (55 or –55A and 60),
nuts (65) and gasket (67).
(g) Install ground lug (25) to case (5) using screw (30), nylon washer (35) and
nut (40).
(h) Apply Loctite Sealant No. 404 to groove of seal (75) and install on case
(5). No gap is permissible at ends of seal.
(i) Install case (5) using screws (10) and nylon washers (15). If removed
during disassembly, replace decal (135) and/or nameplate (140).
(j) Safety wire screws (10) upon completion of assembly.
(3) Storage Instructions
(a) Place protective plastic caps over electrical connectors (EP10 and EP 12
dust covers or equivalent).
(b) Place LLT together with a small envelope of desiccant in a polyethylene
bag.
(c) Seal bag vapor tight.
(d) Label bag with LLT part number and date of overhaul.
NOTE: LLT contains no cure dated items. Packaged LLT may be stored
indefinitely.
